AMG V12 Viella Turntable with 12 J2 Tonearm Hardened 16mm axle bearing, CNC machined ground and lapped Two-sealed, hydro-dynamically lubricated radial bearings with axial bearings featuring static lubrication Stainless steel sub-platter interfaces with platter Decoupled spindle, 2-piece construction CNC machined in house using aircraft grade aluminum Weighted rim for enhanced flywheel effect 12.5″ (318mm) diameter, 24.25 lbs. (11Kg) weight True reflex style record clamp Anodized aluminum Inverted threaded attachment to decoupled spindle Cured and polished axis Motor housing acoustically decoupled from plinth via 5 rubber/metal mounts Backlit capacitive buttons change color with function Precision speed adjustment for each speed Bearing: Dual-pivot design replaces the standard gimbaled bearing Vertical bearing, similar to a technique used in the rotor heads of helicopters Uses two .5mm thick “spring steel wires,” allowing fine azimuth adjustment while eliminating bearing play Horizontal axle is a hardened tool steel, precision ground to a backlash-free fit with a needle roller bearing It is extremely precise, maintenance free, and never requires adjustment Armwand: Aircraft quality Anodized aluminum tube for resonance control 12 gram effective mass Counterweight: 2-piece with Teflon decoupled sleeve Copper Internal Wiring: Multiple gauges of high quality copper Magnetic Anti-skating: Decoupled via ring magnet and 2-bar magnets Magnetic fields isolated in our patented bearing housing VTA: Precision locking system allowing easy adjustment during play Special features Total Weight Approx. 56.4lbs Dimensions 20 5/8″ x 8″ x 12 7/16″ Speed Ranges 33.3, 45, and 78 rpm speeds with electronic on/off Download Manual Click here to download manual pdf. Type Unsuspended, belt-driven turntable with integral tonearm outboard motor controller, and screw-down clamp Motor Lorenzi 2-pulse, low-speed brushless Precision 24v DC motor with auxiliary reluctance moment Sintered bronze bearings How to find us Contact Us to book a demo in our Elland Listening room. Burley Street, Elland, HX5 0AQ Phone: 01422 250590 Email:
